Universal Air Conditioner UN, Car Air Conditioner 12V 30W Universal A/C 32 Pass 4 Way Coil, Maximum Airflow and Cooling Capacity 3 Flow Speed Air Conditioning Evaporator for Car RV

Brand: TBVECHI

Color: Black

Features:

• [Universal A/C Evaporator] Underdash Evaporator is a Premium Quality Universal under dash A/C evaporator, intended for use in adding an air conditioning system to a vehicle which did not have A/C from the factory. It is most popularly used in classic cars, motorhomes, and heavy equipment.
• [Quality Material] The Universal Car Truck Underdash is made of high quality material.All high impact injected plastic case.High quality expansion valve.High qualitiy thermostat and rotative 3 speed blower switch.
• [Specific Advantages] Cool Only Unit with Fittings on Driver Side of Units.32 pass 4 way coil for maximum airflow and cooling capacity.Mounting brackets and drain hose and T included
• [Installation Method] Black screw position-connected to the negative line of the car battery;Red line-connect the positive line of the car battery;Green line-connect the compressor control line
• [Installation Method] 1. Black screw position-connected to the negative line of the car battery; 2. Red line-connect the positive line of the car battery; 3. Green line-connect the compressor control line; 4. The car must have compressor and other air-conditioning system accessories before installing 404 evaporator.

Details: Details T-Tube&Drain Hose: Attaching the T-tube to the 3.28ft long drain hose ensures smooth, efficient drainage. 2 Mounting Brackets: The mounting brackets with pre-drilled holes make it easy to secure the product in place. Application It can be used for all types of cars and is a universal type. Specifications Material: ABS Color: Black Style: Modern Type: A/C Evaporator Control Mode: Manual Type Installation Type: Split System Temperature Control: Mechanical Motor Type: All-copper Motor Temperature: 3-8°C/37.4-46.4°F Voltage: 12V Current: 8A Power: 80W Air Flow: 3 Speed Noise: 65dB Maximum Air Volume: 680m³/H Circulating Air Volume: 440m³/H Refrigeration Capacity: 3640kcal/H Refrigerant: R12(Not Included) Number of Cold Aluminium Tubes: 32 Drain Hose Length: 1m/3.28ft Product Size: 40*33.5*13.5cm/15.75*13.19*5.31in Package Size: 46*41*20cm/18.11*16.14*7.87in Gross Weight: 4.6kg/10.14lbs Net Weight: 4.14kg/9.13lbs Package Included 1* Air Conditioning Evaporator 1* Drain Hose 1* T-Tube 2* Mounting Brackets
